HTS Equipment
Over the last few years, we have established two HTS systems use state-of-the-art liquid handlers and multi-mode plate readers. All liquid handlers and readers are either integrated in the full HTS system or setup for stand-alone use with automated plate stackers. Our liquid handling capacities allow us to perform liquid transfer from 25nL to 1000ul between 96 well plates to 1536 well plates. We have several plate readers that can measure all common modalities including absorbance, fluorescence, FP, TRF, TR-FRET, Alpha screen, luminescence, etc.
Liquid Handlers
| INSTRUMENT | MANUFACTURER | TYPE | OPTIONS | OTHER INFO | IMAGE |
|---|---|---|---|---|---|
| Mosquito X1 | TTPTech | Automated Cherry picking | DMSO or aqueous solvents cherry-picking, Volumes: 25 – 1200 nL |
96, 384, 1536-well plates |  |
| Bravo | Velocity 11/Agilent | Automated Pipette Liquid Transfer | Any liquid viscosity. Plate stamping and serial dilutions (row or column), Cherry picking, Volumes: 0.1 – 250 uL | 96, 384, 1536-well plates |  |
| VPrep | Velocity 11/Agilent | Automated Pipette Liquid Transfer | Any liquid viscosity. Plate stamping Volumes: 1 – 300 uL | 96, 384, 1536-well plates |  |
| Felix | Cybio | Automated Pipette Liquid Transfer | Any liquid viscosity. Plate stamping and serial dilutions (row or column), Cherry picking, Volumes: 0.1 – 250 uL | 96, 384, 1536-well plates |  |
| Well Vario | Cybio | Automated Pipette Liquid Transfer | Variable liquid viscosities. Plate stamping. Fix volumnes: 25 or 100nl | 384, 1536-well plates |  |
| EVO100 | Tecan | Automated Pipette Liquid Transfer | Any liquid viscosity. Plate stamping and serial dilutions, Cherry picking, Volumes: 0.5 – 1000 uL | 96 or 384-well plates |  |
| Biomek NXP | Beckman | Automated Pipette Liquid Transfer | Any liquid viscosity. Plate stamping and serial dilutions (row or column), Cherry picking, Volumes: 0.5 – 250 uL | 384, 1536-well plates |  |
| Versette | Thermo | Automated Pipette Liquid Transfer | Any liquid viscosity. Plate stamping. Volumes: 0.5 – 250 uL | 96 well plates |  |
Plate Readers
| INSTRUMENT | MANUFACTURER | TYPE | OPTIONS | OTHER INFO | IMAGE |
|---|---|---|---|---|---|
| H1MF | Biotek | Multimode iterative well scanning | FI, Lum, UV/VIS, FP, TRF | 96, 384, 1536-well plates |  |
| VarioSkan flash | Thermo | Multimode iterative well scanning | FI, Lum, UV/VIS, TRF | 96, 384, 1536-well plates |  |
| CLARIOstar | BMGlabTech | Multimode iterative well scanning | FI, Lum, UV/VIS, FP, TRF, TR-FRET, AS | 96, 384, 1536-well plates |  |
| PHERAstar FSX | BMGlabTech | Multimode iterative well scanning | FI, Lum, UV/VIS, FP, TRF, TR-FRET, AS | 96, 384, 1536-well plates | |
| Cytation 5 | Biotek | Multimode iterative well scanning | FI, Lum, UV/VIS, FP, TRF, TR-FRET, AS | 96, 384, 1536-well plates |  |
Washers and Dispensors
| INSTRUMENT | MANUFACTURER | TYPE | OPTIONS | OTHER INFO | IMAGE |
|---|---|---|---|---|---|
| Combi | Thermo | Liquid Dispenser | Variable liquid viscosities High-speed 8-channel liquid dispenser using a peristaltic pump Volumes: 0.5 – 2500 uL |
96, 384, 1536-well plates | |
| MultiFlo FX(2) | Biotek | Liquid Dispenser with washer module | Variable liquid viscosities High-speed 8-channel liquid dispenser using two peristaltic pump Volumes: 1 – 2500 uL |
96, 384, 1536-well plates |  |
| 405TS (2) | Biotek | Plate Washer | Variable liquid viscosities Plate washer- 96 well manifold Volumes: 50 – 3000 uL. |
96, 384 well plates | |
| EL406 (3) | Biotek | Plate Washer/Dispenser | Variable liquid viscosities Plate washer- 96-192 well manifold Volumes: 50 – 3000 uL. One peristaltic pump and two syringe pumps |
96, 384, 1536-well plates |  |
| Mantis | Formulatrix | Single channel dispenser | Variable liquid viscosities single channel liquid dispenser. Volumes: 0.1 – 400uL | 96, 384, 1536-well plates |  |
Compounds/Sample storage
Automated Western Blots
Various Imagers
RT-PCR
MAGPIX Multiplexing Immunoassay system
